As an alternative to measuring in GMG OpenColor, you can also import measurement files from third-party software.
- On a Characterization / Project page, click the Import button on the Tools & Actions panel.
You can additionally use the characterization data and spot color databases shipped with GMG OpenColor, but it is recommended to print the inks you want to simulate under the exact printing condition (printing process, media type, etc.) you want to proof.
Following the import, you can create a characterization from the measurement data (Tools & Actions > Create Characterization).
Importing several measurement files
To import multiple measurement files, select the files while pressing the Shift key (multi-select) and click Open.
Note: Multiple measurements are automatically combined if they have the same number of inks, ink names, and spectral range.
Can I rename the ink names during import?
The ink names are read out from the selected measurement file. The inks can be renamed by clicking on an ink name. The color preview next to the ink name shows the measured color of the ink, calculated from the
Can I import only part of the measurement file?
You can skip measurements by deselecting single channels in the channel list. In our example, only the measurements of orange, green, blue are used for calculating profiles.
